NEW Colour MultiLED MX Lamps

Over the last few years the MultiLED MX lamp heads from GS Vitec have established themselves as the go to lights for high-speed photographic applications across the world. Photo-Sonics International Ltd. are pleased to announce that these are now available in select colours.

Warm White, Blue, Green, Photo Red, and Near-Infrared versions of the MultiLED MX are now available.

High power colour LED lights have various applications,  key amongst these is the illumination of Particle Image Velocimetry (PIV) experiments where colour light can make visible the particles seeded into the flow stream.  Here the low cost of the colour MultiLED MX lamps, when compared to expensive laser systems, and superior reliability, makes them the go to solution.

For Tomographic PIV, the use of pulsed Red, Green, and Blue LED light are often used. The same colours are also used in Particle Shadow Velocimetry (PSV), a proven and effective alternative to PIV that uses light scattered from seeding particles and techniques to register the shadows of the particles instead.

Due to a lower phosphor content in the LEDs, the colour MX lamps also have a significantly quicker rise and fall time than the MX White, permitting a shortest useable pulse time of 100 nanoseconds.

The following colours are now available for the MultiLED MX lamp:

Colour	Wavelength	Output
95 CRI White	Warm white	30,000 Flux (lm)
Blue	440 - 460 nm	180,000 Flux (mW)
Green	520 - 540 nm	42,000 Flux (mW)
Photo Red	640 - 670 nm	131,000 Flux (mW)
NiR	~810 nm	109,000 Flux (mW)
NiR	~850 nm	100,000 Flux (mW)
NiR	~940 nm	108,000 Flux (mW)



Visit our MultiLED MX product page for further information.
